Passive devices such as resistors, capacitors and inductors are critical components that require precise measurements. Reduce the risk of out-of-tolerance conditions with the help from Integra's test team.
Device Types Include: Capacitors (BME, PME, Ceramic Tantalum, Electrolytic, Power), Resistors, Thermistors, Varistors (Ultra precision, Fixed, Potentiometers), Magnetics, Inductors, Ferrite Bead, Transformers, Filters, Sensors, Crystals, Resonators, Connectors, Cables, Switches and Relays
- Screening and Qualification to various Military and
Aerospace Standards including:- MIL-STD-202
- Resistors: MIL-PRF-39007, 39009, 83401, 55182, 55342, 83410, 26, 914, 39017, 32159
- Inductors: Mil-T-27E, MIL-C-15305E, MIL-C-39010D
- Capacitors: MIL-PRF-39003, 39006, 55365, 55681, 20, 39014, 11272, 23269, 11015
- Connectors: MIL-DTL-12502, 22992, 24308, 26482, 32139, 38999, 83527, 83538, 83513
- Filters: MIL-PRF-15733
- Infant Mortality and Life Test Screening Services
- Screening and Qualification to NASA EEE-INST-002 / SSQ 25001 for Space Application
- Understanding of Issues Associated with BME Capacitors and Providing Comprehensive Screening and Qualification Testing Services
- Extended Temperature Testing to +200˚C
- Full DPA / Failure Analysis Capabilities for Both Military and Space Applications
- DPA/Cross Section per MIL-STD-1580 / SSQ 25000
- Full Failure Analysis and Point of Fault Isolation
Specialized Harsh Environment Testing
- Full Screening and Qualification Testing Capabilities
- Full Electrical Testing
- Capacitance, DWV, IR, Resistance
- Temperature cycle
- Thermal Shock
- Mechanical Testing
- Moisture Resistance
- Humidity
- Burn-In and Voltage Conditioning
- Solderability
- Life Test - (Dynamic, Steady State, HTRB, Intermittent, etc.)
- Real Time X-Ray
- XRF
- Surge Current
- High Impedance Temperature and Voltage Ramp
Capacitor Testing
- Test capability for all types of Capacitors including MLCC, Chip, Ceramic. Tantalum, Glass, Plastic Film, Mica, Variable,
- Testing to all various Military Standards including MIL-PRF- 20, 81, 123, 87164, 87217, 83421, 55365,55681, 55342, 49467, 49470, 14409, 39001, 39003, 39006, , 39022, 39014, 23269. 19978
- Testing & Qualification Support per MIL-STD 202, EEE-INST-002, AEC Testing includes
- Electrical Tests (Capacitance, DF, DWV, IR, DCL, ESR, QF)
- Voltage Conditioning
- Surge Testing
- Humidity Steady State Life
- Voltage Term Limits
- Temperature Coefficient and Drift
- Moisture Resistance
- Life Tests
- Environmental and Mechanical Tests
- MIL-STD-1580 DPA and Failure Analysis
- Tri-Temp Testing
INTEGRA IS READY TO HELP
Lead times for Hi-Rel, Military and Space Grade are extremely long for many capacitors and resistors. Our in-depth knowledge of upscreening capacitors along with our state-of-the-art 24X7 facilities in Wichita, KS and Milpitas, CA, are ready to upscreen commercially available passive devices to shorten your lead times. We will even buy the parts from authorized distributors and provide you fully upscreened parts.
Let's talk: sales_inquiry@integra-tech.com
